Dual-sided electric lifting column with two clamps on opposite faces — two mechanics work the same unit at once, each with their own clamp, hand controller and foot pedal.
The ERS01019D doubles the throughput of the single-column ERS01019: one freestanding base carries an extended column with clamps on both sides, so a second service position needs no extra floor space.
Two independent clamp assemblies ride the same rigid anodised column, one on each face. Each position is driven separately and holds its height firmly with the drive unpowered, so two technicians can raise, lower and rotate their bicycles without waiting for each other.
Each side has its own wired hand controller and foot pedal — hold-to-run on both, and each drive stops the instant its control is released. The cabinet at the base houses the electrics with a serviceable layout, and the whole unit stays freestanding: no wall or bench mounting required.
| Model | ERS01019D |
|---|---|
| Drive | 2 × electric actuator, belt-guided carriages |
| Work positions | Two — one per column face, independently controlled |
| Lift stroke | Full column height, continuous |
| Load capacity | On request — specify bicycle type (per side) |
| Control | Per side: wired hand controller + foot pedal (hold-to-run) |
| Safety | Stops on release; carriages self-locking |
| Clamping | 2 × quick-release bicycle clamp, rotatable head |
| Column | Anodised aluminium extrusion, serviceable profile |
| Base | Freestanding steel floor plate |
| Power supply | Mains — confirm voltage with order |
| Typical use | High-throughput assembly lines, e-bike service centres, training workshops |
| Certification | CE — declaration available on request |
Specifications are typical values for the standard configuration. Custom materials, ranges and certifications are available on request — talk to an application engineer for a tailored datasheet.
Every unit ships with a 24-month parts-and-labour warranty covering manufacturing defects and premature component wear.
A stocked central spares warehouse guarantees critical-part dispatch within 24 hours to 40+ countries.
Our field engineers supervise on-site setup, alignment and first-run calibration, then hand over a signed commissioning report.
